AMR-RMV2.5G30.U
Armor Axial Pressure Washer Pump 2 5 GPM 3 000 PSI
Armor Axial Pressure Washer Pump 2 5 GPM 3 000 PSI
Couldn't load pickup availability
Features:
This universal direct drive horizontal mount axial plunger pump will fit any horizontal shaft gasoline powered engine with a 3/4" key style shaft. It requires a minimum 160cc gasoline engine and delivers up to 3,000 PSI and 2.5 GPM of water flow. This pump bolts directly onto a gas engine up to 6.5 HP.
Shipped ready-to-install! Remove your old pump, align the new pump with shaft key in place, then bolt & go!
Armor pumps are a quality made economical option for most factory original pumps. It is most commonly used with Honda GC160 motors with a horizontal shaft.
Technical Specs:
- 3,400 RPM Max
- Accepts 3/4" Key Style Engine Shaft
- 22mm x 14 Male Outlet Thread
- Inlet Thread Female Garden Hose Connector
- Adjustable Unloader Valve
- 140 Degree F (60 Degree C) Maximum Water Temperature
- Prefilled with Oil
- Thermal Relief Valve
- Soap/Chemical Injection Kit
- Brass Manifold & Stainless Steel Pistons for Long Life
- Maximum Flow - 2.5 GPM
Compatible With These Pressure Washer Models:
Simpson - MSH3125-S, MS60763-S, PS3228-S, MS60968-S, PS60842, PS60982, PS60841, PS60981, PS60551, PS60735, PS60774, PS60629, PS60763, PS60689
BE - BE316HA, BE275HAS
Stanley - SXPW3425, SXPW3324K
Generac - 6882, 7122, 7019, 6924, 6007, 8543, 6590
Karcher - G3500OHT, G3500OCT, 1.107-386.0, 1.107-388.0, 1.107-387.0, 1.107-280.0, 1.107-336.0, 1.107-332.0, 1.107-333.0, 1.107-334.0
Westinghouse - WPX3100
Champion - 100384, 100385, 100382, 76525
Cub Cadet - CC3425, 60934, 60603
Dewalt - DXPW60603, DXPW3425, 60690
Excell - EPW2123100, EPW1792500
BE - P2765HC, B3065HJ, B275HA
Ryobi - RY803600
Cambell Hausfeld - PW340200
Powermate - 7131, 7130
Powerplay - SR23OHH25ARNLQC, SR233HX27ARTLQC, SR232HX26PPLSE2
And Many Others...
