Eagle 5 5 HP 10 Gallon ES Air Compressor

Eagle 5 5 HP 10 Gallon ES Air Compressor

TT55GE

Regular price $1,840.55 USD
Regular price $2,496.20 USD Sale price $1,840.55 USD
Sale Sold out



THIS ITEM SHIPS TRUCKLINE

LIFT GATE FEES AND RESIDENTIAL FEES MAY APPLY IN ADDITION TO SHIPPING CHARGES

Features:
  • 5.5HP
  • CFM@ 100 PSI 12.5
  • Maximum Rated PSI - 150
  • Receiver Capacity- 10 Gal
  • Honda GX160ut1zxe2-r Motor
  • Dimensions- 50x18x24
  • Weight- 190 lbs
  • Rugged Compressor With Cast Iron Cylinders
  • V Design minimizes vibration, improves cooling & extends compressor life
  • Individual & removable cylinders for smoother & cooler operations
  • 10 Gallon capacity twin tanks- the largest in the industry
  • Steel rim pneumatic tire for easy handling and maneauverability
  • Convenient oil drain on front of unit
  • Easy view oil sight guage
  • Metal Air Filters with "Auto Drop" feature
  • High efficiency reed valves for maximum performance
  • Efficient heat removal from pulley-fan for cooler running and longer life
  • Sturdy metal belt guard
  • Engine slow-down control- reduces operating costs and unnecessary wear
  • Outlet control regulator with quick connectors
  • This Product Is Delivered By Truck-line.  There Could  Be Liftgate and Residential Fees Added to the Shipping Cost.
  • 1 Year Factory Warranty
  • TMI160000

Item Description  Part Number
1 Compressor w/ Flywheel PV02A Pump Assembly
2 Pressure Gauge PG200-2.5SI1/4
3 Discharge Tube (2.5ft) ASSY TU-23-AL
4 Air Receiver (tank) 10TT41X5-B
5 Drain Cock -Assembly 240-B
6 V-Belt 4L530
7 Belt Guard TT-GUARD
8 Engine GX-160UT1QXE2-R
9 Unloader NRP-A-95-125
10 Pulley - Engine MA38X3/4
11 Safety Valve PSV1/4-170
12 Engine Control w/ Cable TCP-48
13 Handle Grip TT-GRIP
14 Vibration Dampner TT-FOOT
15 Pneumatic Wheel TT-WHEEL-SQ-FF
16 Coupler CPL-DUO
17 Hose Assembly - Regulator TT-HOSE-B
18 Pressure Gauge (regulator) PT0160
  Eagle Compressor Oil EAOIL10
Regulator R202-1/4
Axle WA1001



 Item Description Part Number
Quantity
1 Intake Filter Assembly 51111-5600 2
2 Cylinder Head 52122-0101 2
3 Lift Limiter for Discharge Valve Plate 51121-3102 2
4 Valve Plate 52122-2101 2
5 Valve Plate to Head Gasket 52122-2105 2
6 Discharge Valve Reed 51121-2103 4
7 Intake Valve Reed
52122-2103 8
8 Valve Plate to Cylinder Gasket 52122-2104 2
9 Piston 51122-5101 2
10 Piston Pin 51122-5112 2
11 Piston Pin Snap Ring 51121-5107 4
12 Connecting Rod c/w Dipper 51122-5120 2
13 Metal Triangle for Valve Plate Assy. (Not Shown) 51121-3101 2
14 Cylinder 52122-4101 2
15 Oil Filler Cap 51111-4719 1
16 Cylinder to Crankcase Gasket 51122-4103 2
17 Oil Sight Glass c/w Gasket 51111-4770 1
18 Crankcase 51122-4701 1
19 Crankshaft 51122-4601 1
20 Front Bearing 83501-6205 1
21 Rear Bearing 83501-6205 1
22 Crankcase to Rear Bearing Housing Gasket 51122-4704 1
23 Rear Bearing Housing 51122-4703 1
24

Oil Seal

51122-4708 1
25 Crankcase Breather 51111-4761 1
26 Flywheel 51122-6601 1
27 Front Bearing Housing
51122-4706 1
28 Crankcase to Front Bearing Housing Gasket 51122-4707 1
29 Connecting (Interstage) Tubing 51122-7710 1
Interstage "Y" Fitting 51121-7702 1
Interstage "Elbow" Fitting 51112-7701 1
Eagle Oil (350ml or 12oz) EAOIL10 1
1/4" Street Elbow (Oil Drain) STREL1/4
1



 Item Description Part Number Quantity
A Intake Filter Element Kit Includes: 51121-5614C 1
- 2x Intake Filter Elements Per Pump
B Valve Repair Kit Includes: 101000-165 2
Valve Plate to Head Gasket (Item 5)
2x Discharge Valve Reeds (Item 6)
Intake Valve Reed  (Item 7)
6x Valve Plate Screws
Metal Triangle for Valve Plate Assy. (Item 13)
C Ring Repair Kit Includes: 101000-265 2
Valve Plate to Head Gasket (Item 5)
Valve Plate to Cylinder Gasket (Item 8)
2x Compression Rings
1x Oil Control Ring
Cylinder to Crankcase Gasket (Item 16)
D Valve Plate Assembly (Not Shown) 51121-2100 2
E Flywheel Fastener Kit
51122-6602 1
Unloader 52122-0120 2
Unloading Elbow 69926-050101 1
Unloading Tee 69927-050101 1
Unloading Tube TU-1/4-CU 3ft
Cylinder Head 51121-0101U 2

Items Not Shown:
Woodruf Key for Engine 3/16x3/16x11/2 1
Woodruf Key for Pump (PV02A) 51122-4606 1
Grommet for Bullwhip 3203 GROMMET 1
